ARCHITECTURE PVB
Ting Mai Architectural PVB FILM is the highly transparent standard PVB film with excellent adhesion for laminated safety glass in architectural glazing. Containing a highly efficient UV stablizer (strongly reduced yellowness index), it also displays proven long-term stability. Depending on the glass assembly, performance classes ranging from P1A to P5A (to EN 356) in penetration tests are possible. It is available in widths of 300 to 3500 mm with a PE interleaf.
l Normal size
l Standard product for all laminating processes.
l PHYSICAL DATA
l Normal size
| Thickness | colour | width | length(m) |
| 0.38 | All colors are available | 450-3500mm | 400 |
| 0.76 | All colors are available | 450-3500mm | 200 |
| 1.14 | All colors are available | 450-3500mm | 150 |
| 1.52 | All colors are available | 450-3500mm | 100 |
l Standard product for all laminating processes.
| Film Thickness | Colour | Light Transmittance | Light Reflectance | UV Transmittance | G-Value | Shading Coefficient |
| [mm] | ||||||
| 0.76 | Clear | 88 | 8 | 0.3 | 79 | 97 |
l PHYSICAL DATA
| Properities | Unit | Test method | Typical values |
| Density | g/cm3 | DIN 53479 | 1.065 |
| Refractive index | DIN 53491 | 1.482 | |
| Thermal conductivity | W/mk | DIN EN 12939 | 0.2 |
| Thermal expansion coefficient | 1/k x 10-4 | 2.2 | |
| Specific heat | J/gk | DIN 52616 | 1.85 |
| Tensile Strength | N/mm2 | ISO 527 | >23 |
| Tensile elongation | % | ISO 527 | >280 |
